ECLD: Fiberwood™ Curved Linear Bar Diffuser

The Fiberwood™ Curved Linear Bar Diffuser is a high-temperature manufactured nozzle style in the ELD series. Made from environmentally friendly resins and fibers, it is 4mm thicker than traditional aluminum alloy nozzles, with a material thickness of 6mm. It boasts numerous design and novelty patents. SGS testing reports show that its thermal conductivity is ten times higher than traditional metals, making it one of the most popular products among users in the past decade.

Standard Construction

  • Material: Extruded Fiberwood
  • Nominal length: 100mm - 1500mm
  • Nominal Width: 50mm - 800mm
  • Minimum Radius: R=150mm
  • Minimum Height: Neck 28mm (+2mm For Blank-off Plate)
  • Total Height: 34mm ( Neck 28mm+Fiberwood 6mm)
  • Oversize: Multiple sections with aglinment pins
  • Curved Corner/Trapezium construction also available
  • Finish: Enamel Paint/Powder Coat/Mil/Woodgrains/etc.,

Options

  • Flange: 19mm Only
  • Blade Deflection: 0° Only
  • Core: Removable Core/Fixed
  • Accessories: Blank-off Plate/Perforated Plate/etc.,
  • Color: RAL/PANTONE/NIPPON/DULUX ICI/etc.,

How to order

  • Fiber curved matte white 0 degree leaf - 19mm edge - movable bladder - blackened - round diameter neck gauge Dia. 2000
  • Code: ECLD-OM/19/R/BP/NECK/DIA.2000mm/Matt White
75 (W) x 1000 (L) mm
275 (W) x 1000 (L) mm
250 (W) x 1000 (L) mm
600 (W) x 1200 (L) mm
125 (W) x 1000 (L) mm
100 (W) x 1000 (L) mm
225 (W) x 1000 (L) mm
300 (W) x 1000 (L) mm
175 (W) x 1000 (L) mm
200 (W) x 1000 (L) mm
150 (W) x 1000 (L) mm
Custom sizes are available.

BASE SIZE

Removable Core
Fixed Core

CORE

0 Degree Deflection

BLADE DEFLECTION

Both sides are advantageous (20 sides)
Single-sided sealing (20 sides)
Boundless
20 mm Frame (20 sides)

FRAME

unnecessary
Perforated Plate (吼冚)
Blank-off Plate

ACCESSORIES

Border Calculation Formula

    border Neck Tianhua left a roar Wind throat Neck height
    20mm B-26mm B-15mm B-20mm 28mm
    - - - - -
    • B = Base Size (Meter)
    • Assuming a 25mm edge is chosen, the face value is 150mm.
    • Neck gauge = 112mm
    • Ceiling height = 120mm
    • Air vent hole = 115mm

Vent neck height (ceiling depth allowance)

    High neck of the air blower

    • 20mm side: 28mm neck height. If it is too wide, a 30mm neck height is required to make the back flat and stiffer.
    • The thinnest it can be made with a neck height of 25mm, but there are no areas that have been hardened.

TEST CERTIFICATION

    • ANSI/ASHRAE Standard 70-06 "Method of Testing the Performance of Air Outlets and Air Inlets"
    • BS 476-6: Fire tests on building materials and structures- Part 6: Method of test for fire propagation for products.
    • BS 476-7: Fire tests on building materials and structures-Part 7 method of test to determine the classification of the surface spread of flame of products.

If you need any assistance, you can consult our 24-hour online text customer service / customer service mailbox , and we will provide you with service at any time.
