ASBSE: Aluminum Hinged Single Deflection Grille

The Hinged Single Deflection Grille comes with a standard or separate airflow control valve (OBD). Unlike the ASBSD Hinged Double Deflection Grille, it only has a single layer of unidirectional blades that can be adjusted independently to control the airflow direction, while the airflow control valve provides airflow volume control. The ASBSE is ideal for commercial, residential, restaurant, parking lot, and restroom applications.

Standard Construction

  • Material: Extruded Aluminum
  • Nominal length: 100mm - 2500 mm
  • Nominal Width: 50mm - 1200mm
  • Oversize: Multiple sections with mullions
  • Depth: 50mm
  • Finish: Enamel/Powder Coat/Mil Finish/PVDF/etc.,

Construction Options

  • Flange: 12mm/16mm/19mm/25mm/32mm/others
  • Blade Position: Front Blade Parallel to Short or Long Dimension
  • Core: Hinged Type
  • Accessories: Blank-off Plate (+BP) / OBD/ etc.,
  • Color: RAL/PANTONE/NIPPON/DULUX ICI/etc.,

How to order

  • Aluminum - Matt White - Door Hinged Single Leaf - 25mm Side - Long Leaf - Plush - Internal Measurement 800*400
  • Code: ASBSE-H/25/+PP/NECK/800*400/Matt White
12 mm Frame (4 sides)
20 mm Frame (20 sides)
25 mm Frame (25 sides)
32 mm Frame (32 sides)

FRAME

No additional accessories required
Aluminum Air FIlter 20mm thickness (6 minutes thick)
Aluminum Air Filer 25mm thickness (1" thick)
Blank-off Plate
Mosquito Net
Opposed Blade Damper (O.B.D.)
Perforated Mesh
Perforated Plate (吼冚)
Wired Mesh
Stainless Steel 304 Air Filter 20mm thickness
Stainless Steel 304 Air Filter 25mm thickness

ACCESSORIES

Longer leaves in front (ASD-H)
Shorter leaves in front (ASD-V)

BLADE POSITION (RECTANGULAR)
